Reverse Engineering the PSP Media Engine: From Empty Stubs to Stable Video Streaming

The Problem: Error 0x806201FE on ARK-4 CFW

The PSP contains a dedicated coprocessor called the Media Engine (ME) — a second MIPS CPU clocked at up to 333 MHz, designed specifically for multimedia decode. Sony’s games and UMD movies use it for H.264, MPEG-4, AAC, and ATRAC3+ decoding. Early homebrew video players like PMPlayer and PMP Mod successfully used the ME on older CFW configurations, proving it was accessible from homebrew in principle.

On our hardware — a PSP-3001 running ARK-4 CFW on firmware 6.61 — the official sceVideocodec API returns error 0x806201FE on every call. The higher-level sceMpeg API fails too, as it internally delegates to sceVideocodec and hits the same wall. The root cause turned out to be CFW-specific: the kernel modules that bridge user-mode codec calls to the Media Engine are not loaded by sceUtilityLoadModule on this configuration.

We set out to understand exactly why the API fails on ARK-4 and whether there was a way to communicate with the ME directly — bypassing the broken stubs entirely. What we found was a complete, previously undocumented kernel driver architecture and RPC protocol that documents how Sony’s codec firmware communicates with the ME.

The Two CPUs Inside Every PSP

┌─────────────────────────────────────────────────┐
│                 Tachyon SoC                      │
│                                                  │
│  ┌──────────────┐        ┌──────────────┐       │
│  │  Main CPU     │        │  Media Engine │       │
│  │  Allegrex     │        │  ME (VME)    │       │
│  │  MIPS R4000   │        │  MIPS R4000  │       │
│  │  1-333 MHz    │        │  1-333 MHz   │       │
│  │              │        │              │       │
│  │  Runs games, │        │  H.264 decode│       │
│  │  homebrew,   │  RPC  │  AAC decode  │       │
│  │  OS kernel   │<------>│  MPEG-4      │       │
│  │              │        │  ATRAC3+     │       │
│  └──────────────┘        └──────────────┘       │
│         │                       │                │
│    Main RAM (64MB)       eDRAM (2MB)            │
└─────────────────────────────────────────────────┘

Runtime Module Discovery

Our kernel PRX (oasis-plugin-psp) hooks sceDisplaySetFrameBuf to draw an overlay UI on top of running games. We added a “Dump ME FW” menu item that enumerates all loaded kernel modules during UMD Video playback — specifically while playing a Spider-Man 2 UMD movie disc.

The initial dump returned only 32 modules. A subtle API quirk was responsible: sceKernelGetModuleIdList’s second parameter is the buffer size in bytes, not the element count. With a 128-entry buffer of SceUID (4 bytes each), the correct size parameter is 512, not 128. After fixing this, we found 68 modules loaded during UMD video playback.

Buried in the list were two modules that do not appear during normal homebrew execution and are not documented in any public PSP SDK or wiki:

This was the first clue. The avcodec.prx loaded during normal homebrew execution contains empty stubs — functions that exist but do nothing. During UMD boot, the firmware loads a different set of modules that include the actual ME driver code. The error 0x806201FE comes from these empty ME submission stubs returning failure.

ME Driver Architecture

With the module names in hand, we used sctrlHENFindFunction (an ARK-4 CFW API that resolves kernel function pointers by library name and NID) to map the imports of sceMeCodecWrapper. It imports from six internal ME driver libraries:

In total, we extracted 47 NIDs for internal ME driver interfaces. These NIDs are not present in any public NID database. The ME firmware itself is loaded from flash0:/kd/resource/me_t2img.img — a 392 KB encrypted image.

Inter-processor communication uses two kernel synchronization primitives: a semaphore named SceMeRpc for mutual exclusion and an event flag named SceMediaEngineRpc for completion signaling. All communication flows through a 40-byte command buffer at a fixed uncached memory address:

ME RPC Command Buffer: 0xBFC00600 (40 bytes)

Offset  Size   Field
------  -----  -------------------------------
+0x00   4B     Command ID
+0x04   4B     (reserved/padding)
+0x08   4B     Parameter 1
+0x0C   4B     Parameter 2
+0x10   4B     Parameter 3
+0x14   4B     Parameter 4
+0x18   4B     Parameter 5
+0x1C   4B     Parameter 6
+0x20   4B     Parameter 7
+0x24   4B     Parameter 8
+0x28   4B     Return value (ME writes back here)
+0x2C   4B     (reserved)

The address 0xBFC00600 is in the uncached KSEG1 region, ensuring cache coherency between the two processors without explicit flush/invalidate. Every ME operation follows the same seven-step sequence, extracted from the disassembled wrapper functions:

ME RPC Dispatch Sequence

1. WaitSema(SceMeRpc)              // Acquire exclusive ME access
2. Write cmd + params to 0xBFC00600  // Fill command buffer
3. DcacheWritebackInvalidate()       // Flush CPU data cache
4. sceSysregMeResetEnable()          // Trigger ME interrupt (!)
5. WaitEventFlag(SceMediaEngineRpc,  // Block until ME signals
                  1, WAIT_AND)       //   completion via event flag
6. Read return value from 0xBFC00628 // ME wrote result here
7. SignalSema(SceMeRpc)              // Release exclusive access

The use of sceSysregMeResetEnable as the interrupt trigger was unexpected. Rather than a dedicated IPC interrupt line, Sony repurposed a SysReg reset signal as a doorbell mechanism. The ME firmware watches for this pulse and reads the command buffer in response.

Command ID Map

From the disassembly, we mapped 22 RPC command IDs to their functions:

Every video function checks a version constant 0x05100601 before dispatching. This appears to be a firmware compatibility marker — the ME firmware must report a matching version during its boot handshake. The module entry point in sceMeCodecWrapper performs the full ME boot sequence: enabling SysCtrl bus gates at 0xBC100000, configuring the ME PLL at 0xBCC00010, flushing caches, setting up COP0 interrupt routing, decrypting the ME firmware from flash0:/kd/resource/me_t2img.img via the Kirk crypto engine, and releasing the ME from reset.

The Breakthrough: mpeg_vsh370.prx

With direct ME driver calls producing initialization errors (the ME responded but needed the correct multi-step initialization sequence), we pivoted to the sceMpeg API — the higher-level interface that Sony’s own games use. We tried syscall hooks to redirect calls through the VSH (Visual Shell) library, loaded mpeg_vsh.prx directly, and tested every combination of AvMpegBase and mpeg_vsh370.prx. All returned 0x80628002 (AVC_DECODE_FATAL).

A critical discovery: mpeg_vsh370.prx imports 59 functions from the sceMpeg library (self-referencing). When the kernel links these at sceKernelStartModule time, it registers sceMpeg as an available library, which triggers re-linking of the EBOOT’s weak import stubs. This meant we could call sceMpeg functions through mpeg_vsh370 without any kernel PRX or bridge module. But decode still returned 0x80628002.

PMPlayer source code: the missing parameters

PMPlayer Advance (by cooleyes, DavisDev/pmplayer-advance on GitHub) successfully decodes H.264 on this exact PSP. Reading its source code (/ppa/mod/mp4avcdecoder.c) revealed three critical differences in the sceMpegCreate call:

The “unknown” parameters in sceMpegCreate were never documented in PSPSDK or any public reference — they were only visible in PMPlayer’s source. Without the DDR top pointer, the ME’s codec firmware had no output buffer to write decoded YCbCr frames, causing every sceMpegAvcDecode call to return 0x80628002 (AVC_DECODE_FATAL).

H.264 decode: working

After applying all three fixes, the full decode pipeline worked on real PSP hardware. Confirmed with a 656×480 H.264 stream from archive.org (Bits and Bytes, 1983). The working init sequence:

sceMpegInit() = 0x0
sceMpegQueryMemSize(5) = 49535        // mode 5 for >480p
DDR top: 2MB @ 0x9000000 (4MB-aligned)
sceMpegRingbufferConstruct(8 packets) = 0x0
sceMpegCreate(mpeg, data, 49535, &rb, 512, 5, 0x9000000) = 0x0
sceMpegRegistStream(mpeg, 0, 0) = OK
sceMpegInitAu(mpeg, 0x9010000, &au) = 0x0   // ddrtop + 0x10000, 0xFF-filled
sceMpegAvcDecodeMode(mpeg, {-1, Psm8888}) = 0x0

The per-frame decode sequence feeds AVCC-format NAL data (length-prefixed, directly from MP4 container) via sceMpegGetAvcNalAu, then decodes via sceMpegAvcDecode. The ME outputs YCbCr which is converted to ABGR via sceMpegBaseCscAvc (hardware color space converter). Everything initializes. Frames decode. Video appears on screen.

Then, after exactly ~90 frames, the video freezes and never recovers.

Streaming Performance

Before investigating the deadlock, we eliminated a massive performance bottleneck in the streaming pipeline. The PSP’s 333 MHz Allegrex CPU and slow heap allocator were being hammered by per-frame allocations:

Total: ~48 MB/s of heap allocation churn eliminated on a 333 MHz MIPS CPU with a basic allocator. These optimizations make the first ~3 seconds of video smooth and responsive, and they remain valuable regardless of the deadlock fix.

The 70-Frame Deadlock

The content is 656×480 Main profile H.264 (mode 5 in the ME’s terminology). The first ~75 decoded frames are perfect — zero errors, zero corruption. Then sceMpegAvcDecode enters and never returns. The video thread blocks permanently. Audio continues on its own thread, but the I/O thread eventually stalls too (blocked on video queue backpressure), and the stream dies.

We added a DECODE_STEP atomic watchdog: the decode function sets step=1 before sceMpegGetAvcNalAu, step=2 before sceMpegAvcDecode, step=3 before sceMpegAvcDecodeDetail2, step=4 before sceMpegBaseCscAvc, and step=0 on return. The main thread checks this every 2 seconds. Result: step=2 every time. The hang is inside sceMpegAvcDecode itself.

We then systematically tested every mitigation we could think of:

The deadlock is not caused by DPB overflow, cache coherency, decode speed, pixel format, or buffer sizes. It’s a hard ~90-frame limit in the ME firmware’s mode 5 code path. Mode 4 (≤480p) works indefinitely but cannot decode >480p content at all.

Inside mpeg_vsh370.prx

The deadlock is inside the loaded PRX, not in our code. To understand it, we needed to trace the full call chain from our Rust sceMpegAvcDecode call through the PRX to the blocking point. We disassembled the 42 KB code segment of mpeg_vsh370.prx using Capstone (MIPS32 little-endian). Matching the loaded function’s prologue bytes against the raw PRX identified it as VA 0x71c0 — one of four identical dispatch wrappers.

sceMpegAvcDecode Call Chain (mpeg_vsh370.prx)

VA 0x71c0  dispatch wrapper
    |  checks init state (< 0x3E0 -> return error)
    |  saves registers, calls real function
    v
VA 0x1078  real sceMpegAvcDecode
    |
    +-- 0x26e4  validate MPEG handle
    +-- 0x616c  AU stream lookup
    +-- 0x8650  ME decode trigger <-- BLOCKING FUNCTION
    |     |
    |     +-- 0x8234  WaitSema(mpeg_data+0x66c)  // mutex acquire
    |     +-- 0x9fd4  KERNEL IMPORT STUB <-- INFINITE WAIT
    |     +-- 0x82c4  SignalSema(mpeg_data+0x66c) // mutex release
    |
    +-- 0x8880  pre-CSC setup
    +-- 0x8a80  ME decode data copy
    +-- 0x9f6c  kernel syscall (in loop)

The blocking point: kernel import stub 0x9fd4

Function 0x8650 is the critical wrapper. It acquires a mutex semaphore at mpeg_data+0x66c, calls the kernel import at VA 0x9fd4, then releases the mutex:

// VA 0x8650 -- ME decode trigger
lw    $a0, 0x240($s0)      // load semaphore ID
jal   0x8234               // WaitSema (acquire mutex)
move  $a0, $s1             // decode context
jal   0x9fd4               // KERNEL CALL -- blocks forever
move  $a1, $zero
lw    $a0, 0x240($s0)      // load semaphore ID
jal   0x82c4               // SignalSema (release mutex)
move  $v0, $s1             // return result

The import stub at 0x9fd4 is patched by the kernel at module load time to jump into the kernel’s ME RPC handler. That handler calls WaitEventFlag(SceMediaEngineRpc, 1, WAIT_AND|CLEAR, &out, 0) with timeout=0 (infinite). When the ME coprocessor deadlocks after ~90 frames, it never sets the event flag, and the wait blocks forever. Signalling the mutex from another thread has no effect — the current holder is past the mutex, stuck in the kernel.

Three Solutions

With the root cause identified — the ME firmware hangs after ~90 mode 5 frames and the kernel waits forever for a completion signal that will never arrive — we developed three solutions of increasing robustness.

Solution A: Runtime Binary Patching

The first approach: prevent the deadlock by patching the loaded PRX in memory. After the decoder initializes, we compute the PRX base address from the resolved import stub (a j <target> instruction that the kernel patched at load time). The jal 0x9fd4 instruction at PRX VA 0x8678 is the call to the blocking kernel function. After 85 frames (safely before the ~90 deadlock threshold), we overwrite it:

// Before patch (normal ME decode):
0x8678: jal 0x9fd4           // call kernel ME RPC
                              // -> WaitEventFlag(infinite) -> DEADLOCK

// After patch (skip ME call):
0x8678: addiu $v0, $zero, -1 // return error immediately
                              // -> caller sees error, continues

The patch is a single MIPS instruction replacement: 0x2402ffff (addiu $v0, $zero, -1) overwrites the jal instruction. We flush the D-cache after patching to ensure the CPU fetches the new instruction. Result: ~70 decoded video frames (~2.3 seconds at 30fps), then the patch activates and every subsequent decode returns an error. The video thread handles errors gracefully. Audio plays uninterrupted for the full stream duration. Tested with 940+ frames processed, zero crashes.

Downside: video stops updating after ~2 seconds. The patch is a permanent kill switch — once applied, no more frames can be decoded until the decoder is destroyed and recreated.

Solution B: Kernel PRX Watchdog Hook

The ideal fix would add a timeout to the infinite WaitEventFlag call. We could not enumerate the event flag UID directly (scanning UIDs 1–65536 from both user mode and kernel plugin threads returned zero results). Instead, we took a different approach: hook sceKernelWaitEventFlag itself from the kernel PRX.

The key insight was applying the timeout selectively. The PSP kernel calls WaitEventFlag frequently for many subsystems — graphics, audio, file I/O. We cannot add a timeout to all of them. Instead, we use the bit pattern parameter to identify ME RPC calls: the ME completion flag uses bit pattern 0x1 with WAIT_AND|CLEAR mode and infinite timeout. When the hook detects this signature, it replaces the infinite timeout with a 5-second deadline.

When the timeout fires, sceKernelWaitEventFlag returns an error instead of blocking forever. sceMpegAvcDecode propagates the error to our video thread, which handles it gracefully: log the timeout, skip the frame, and continue. The video thread never blocks permanently.

Downside: after the first timeout, the ME is in an undefined state. Subsequent decode attempts may also timeout, effectively ending video decode. But the system remains stable and audio continues.

Solution C: P/B-Frame Skipping (Production)

The production solution avoids the deadlock entirely by managing what gets sent to the ME. The insight: the ~90-frame deadlock occurs because the ME accumulates internal state (reference frame buffers, DPB entries) that eventually exhausts some firmware resource. If we prevent that accumulation, the deadlock never triggers.

The approach: decode the first ~50 frames per keyframe interval normally, then skip all P-frames and B-frames until the next keyframe (IDR NAL unit). This creates a repeating cycle:

Keyframe 0   --> decode frames 0..50   --> skip P/B until keyframe 1
Keyframe 1   --> decode frames 0..50   --> skip P/B until keyframe 2
Keyframe 2   --> decode frames 0..50   --> skip P/B until keyframe 3
  ...

Each keyframe resets the ME’s internal reference state, preventing accumulation. The frame threshold of ~50 is well below the ~90-frame deadlock point, providing a safety margin. Video updates on every keyframe (typically every 1–3 seconds depending on the encoder’s GOP structure), creating a slideshow-like but functional display. Audio plays continuously without interruption.

Result: verified 2+ minutes stable on real PSP hardware with zero deadlocks, zero crashes, continuous audio, and periodic video updates. This is the solution shipped in production.

The Pixel Pipeline

Getting decoded frames from the ME to the screen required solving several hardware-specific problems. The ME’s sceMpegBaseCscAvc performs hardware color space conversion (YCbCr to RGB), but the output format and memory requirements are tightly coupled to the decode mode.

The CSC output uses Psm8888 pixel format (ABGR, 32 bits per pixel). We discovered that the CSC output format is determined by the sceMpegAvcDecodeMode setting passed during initialization — not by any parameter to the CSC function itself. Setting the wrong decode mode produces garbled output even if the CSC call succeeds.

The CSC output buffer must be in uncached memory (ptr | 0x4000_0000) to ensure D-cache coherency between the ME and the main CPU. Without this, the main CPU reads stale cache lines and displays corrupted frames. After the CSC completes and we upload the pixel data to a GU texture, a D-cache flush on the texture buffer is required for the GU (Graphics Unit) to see the updated data. One additional fix: the CSC outputs alpha=0x00 on every pixel, so a post-conversion alpha fixup sets every pixel’s alpha to 0xFF for correct GU compositing.

Graceful Degradation

In a streaming application, reliability matters more than maximum decode quality. The production system implements a three-tier fallback chain:

1. Normal video decode — P/B-frame skipping keeps the ME under the deadlock threshold. Video updates on keyframes, audio plays continuously.
2. Watchdog catches deadlock — if the ME does deadlock (edge case: keyframe interval longer than expected), the kernel hook’s 5-second timeout fires. sceMpegAvcDecode returns an error. The video thread sets an ME_LEAKED flag and does not call sceMpegDelete — calling delete on a busy ME causes a hard crash. The decoder resources are intentionally leaked.
3. Audio-only continues — with the ME_LEAKED flag set, the video thread stops attempting decode. Audio streaming continues via sceAudiocodec on a separate thread (audio decode does not use the ME’s video path). When the user switches to a different channel, the ME_LEAKED flag prevents reinitializing the video decoder, avoiding a crash from creating a new sceMpeg instance while the old one’s ME state is corrupt.

This design ensures that no matter what the ME firmware does, the application never crashes and audio never stops. The worst case is a frozen video frame with continuous audio — acceptable for a streaming TV app on 2005 hardware.

Lessons Learned

• The ME firmware has a hard ~90-frame limit in mode 5. It’s not DPB size (proven by SPS patching making it worse), not cache coherency (proven by full D-cache flush), not buffer sizes (proven by DDR workspace doubling), and not decode speed (proven by throttling). The limit is in the ME coprocessor’s internal state.
• Every sceMpeg flush/reset API crashes on mpeg_vsh370.prx. sceMpegFlushAllStream, sceMpegAvcDecodeFlush, and sceMpegInit all cause hard freezes when called during active decoding. The decoder cannot be safely reset. Even destruction crashes when the ME is busy.
• Runtime binary patching of loaded PRX modules works. Computing the PRX base from the resolved import stub address, locating a specific instruction by VA offset, and overwriting it with a D-cache flush — all from user-mode Rust — is a viable technique on PSP.
• Kernel event flags are not enumerable from plugin threads. sceKernelReferEventFlagStatus returns errors for all UIDs from both user mode and kernel plugin threads. The hook approach (intercepting the wait call) is more reliable than trying to find the event flag UID.
• Undocumented parameters hide in abandoned source code. The critical sceMpegCreate parameters (mode 4/5, DDR top pointer) were never documented in PSPSDK or any public reference. They only existed in PMPlayer’s source code, which was last updated in 2010. Sometimes reverse engineering the firmware is less effective than reading existing homebrew that already solved the problem.
• EABI32 vs O32 is a systemic issue for Rust on PSP. LLVM’s O32 calling convention breaks every PSP syscall with 5+ arguments. The 29 EABI mappers added to rust-psp fix all known affected functions. This bug blocked child module loading entirely (sceKernelStartModule returned 0x800200D3 from Rust but worked from C).
• Design for graceful degradation, not perfect operation. On hardware with undocumented firmware bugs, the question is not “how do we prevent all failures” but “how do we survive them.” The leak-and-continue strategy keeps the application running even when the ME is in an unrecoverable state.
• 48 MB/s of allocation churn matters on a 333 MHz CPU. Pre-allocating buffers, eliminating per-frame copies, and using kernel semaphores instead of polling are not premature optimizations on embedded hardware — they are the difference between smooth playback and dropped frames.
